Brand Name : JD
Model Number : JD-1063
Certification : CE
Place of Origin : CHINA
MOQ : 1 pcs
Price : Negotiable
Payment Terms : T/T, L/C, D/P, Western Union,
Delivery Time : 15days
Packaging Details : 5 layer cartons
Material : die cast aluminum
Color : black/grey/dark grey/light grey
Ip rating : IP66
Working temperature(℃) : -40 - 50
Cri (ra>) : 80
Input voltage(v) : 100-280VAC
Application : Roadway,outdoor,garden
Lamp luminous efficiency(lm/w) : 110
Warranty(year) : 5
Working lifetime(hour) : 70000
China factory 30w 50w 60w IP66 and led garden post lightsor used for parking
MATERIAL
Casing material Pressure Casted Aluminum ADC12, Powder-Coated Finishing
NEMA Socket
5mm Tempered Glass
Fixtures light commercial outdoor post light fixtures ,
outdoor. Industrial flood lights modern outdoor post light fixtures.
Outdoor post light fixtures outdoor light fixtures ideas.
The best outdoor post light fixtures ideas on pinterest.
.
Features:
* Suitable to diameter 76mm pole.
* High brightness LED chips 100lm/w.
* IP66 waterproof rating
* Different type lens for choice
* Working environment in -40℃to 50℃.
* CE/ROHS/LM79/LM80 for quality assurance and safety operation.
* IES files are available.
* 5 years warranty.
Specification:
Model | JD-1063A 30W | JD-1063B 60W | JD-1063C 100W |
Wattage | 30W | 60W | 100W |
Beam Angle | 150*50/150*80/120*120 Degree | ||
Luminous Flux | 3000lm | 6000lm | 10000lm |
Color Temperature | 2700K~6500K | ||
Input Voltage | AC100-277V, 50-60Hz | ||
Life Hours | 70000 | ||
LED Chip | 3535/ 3030 smd | ||
CRI | Ra>80 | ||
PF | >0.92 | ||
Surge Voltage | 10V/20KV | ||
IP Rating | IP66 | ||
Dimension | L480*W470*H570mm |
![]() |
China factory 30w 50w 60w IP66 and led garden post lightsor used for parking Images |
